Stainless Steel 310S is a low-carbon variant of standard grade 310, and it offers better resistance to oxidation and superior strength at higher temperatures. The lower carbon content in 310S reduces the possibility of carbide precipitation during high-temperature operations, which often results in loss of mechanical properties with time. Due to this, the Stainless Steel 310S Flanges are highly recommended in fields of application where there are continuous temperature changes and low and high temperatures, such as petrochemical processing, power generation, and the chemical industries.

We are involved in offering a comprehensive range of Stainless Steel 310S Flanges to suit different industrial requirements. We deal in SS 310S Slip-On Flanges, which are easy to install and align with the pipes, hence reliably connecting to the piping system for various usages. Also, our SS 310S Weld Neck Flanges are suitable for high-stress applications because of the strongly welded connection that provides a safe and long-lasting joint. We offer SS 310S blind flanges for applications where a pipe connection needs to be securely closed off at the end of a pipeline. We also deal in SS 310S Socket weld flanges used for high-pressure applications and are forged with a recessed pocket into which the pipe is inserted, thus forming a strong, leakproof joint.

One of the primary properties regarding our Stainless Steel 310S Flanges is their excellent oxidation resistance, which enables them to perform reliably in environments up to 1150°C (2100°F). A critical point about high-temperature resistance is that these flanges, being good at resisting high temperatures, turn out to be especially useful in furnace components, heat exchangers, and other types of equipment that go through extreme thermal conditions.

Stainless Steel 310S Flanges Manufacturers in Mumbai, Stainless Steel 310S Flanges Suppliers in Mumbai, Stainless Steel 310S Flanges Stockists in Mumbai, Stainless Steel 310S Flanges Exporters in Mumbai

309/310/310S Stainless Steel Flanges Equivalent Grades

STANDARD	UNS	WNR.	AFNOR	EN	JIS	BS	GOST
SS 309	S30900	1.4828	-	-	SUS 309	-	-
SS 310	S31000	1.4841 / 1.4307	-	X15CrNi25-20	SUS 310	310S24	20Ch25N20S2
SS 310S	S31008	1.4845	-	-	SUS 310S	-	20Ch23N18

Specification of Stainless Steel 310S Flanges

Stainless Steel Flanges Specification : ASTM A182 / ASME SA182
Dimension Standard : ANSI/ASME B16.5, B 16.47 Series A & B, B16.48, BS4504, BS 10, EN-1092, DIN, etc.
Standard : ANSI Flanges, ASME Flanges, BS Flanges, DIN Flanges, EN Flanges, etc.
Size : 1/2" (15 NB) to 48" (1200NB)
Class / Pressure : 150#, 300#, 600#, 900#, 1500#, 2500#, PN6, PN10, PN16, PN25, PN40, PN64 etc.
Flange Face Type : Flate Face (FF), Raised Face (RF), Ring Type Joint (RTJ)
DIN Flanges : DIN 2527, 2566, 2573, 2576, 2641,2642, 2655, 2656, 2627, 2628, 2629, 2631, 2632, 2633, 2634, 2635, 2636, 2637,2638, 2673.
JIS Flanges : JIS B2220 5K, JIS B2220 10K, JIS B2220 16K, JIS B2220 20K
BS Flanges : BS4504 PN 6, BS 4504 PN 10, BS4504 PN 16, BS4504 PN 25, BS4504 PN 40, BS 4504 PN 64, BS 4504 PN 100, BS 4504 PN 160, BS 4504 PN 250, BS 10, BS Table D, BS Table E, BS Table F, BS Table H.

Chemical Alloyion of Stainless Steel 310S Flanges

C	Mn	Si	P	S	Cr	Ni	Fe
309	0.2 max	2.0 max	1.0 max	0.045max	0.03max	22 24	12-15	Balance
310	0.25 max	2.0 max	1.50 max	0.045max	0.03max	24-26	min: 8.0 max: 12.0	Balance
310S	0.08 max	2.00 max	1.50 max	0.045	0.03	24-26	19-22	Balance

Mechanical Properties Of Stainless Steel 310S Flanges

Grade	Tensile Strength ksi (min)	Yield Strength 0.2% ksi (min)	Elongation %	Hardness (Brinell) MAX
309	40	30	40	217
310	Psi – 75000 , MPa – 515	Psi – 30000 , MPa – 205	40%	-
310S	Psi – 75000 , MPa – 515	Psi – 30000 , MPa – 205	40%	-

Physical Properties of 309 Stainless Steel Flanges

Grade	Density lbm/in3	Thermal Conductivity (BTU/h ft. °F)	Electrical Resistivity (in x 10-6)	Modulus of Elasticity (psi x 106	Coefficient of Thermal Expansion (in/in)/ °F x 10-6	Specific Heat (BTU/lb/ °F)	Melting Range (°F)
309	at 68°F: 0.285	9.0 at 32- 212°F	30.7 at 68°F	28.5	8.28 at 32 – 212°F	0.1200 at 68°F to 212°F	2500-2590
