Further, delivered by using best nature of raw substances, these flangesare broadly used being developed and different other related undertakings. Our WNR 2.4068 Flangesare accessible to our critical clients in different extent of estimations, wall thicknesses and sizes at truly sensible rates.
AISI 201 Nickel Alloy Flanges Specification
Dimensions : ANSI B16.5, ANSI B16.47 Series A & B, MSS SP44, ASA, API-605, AWWA, Custom Drawings
Standards : ASTM, ASME Flanges, ANSI Flanges, DIN Flanges, EN Flanges, BS Flanges etc.
Specifications : ASTM B564 / ASME SB 564
Length : 100 mm To 3000 mm Long & Above
Size : 1 / 2″NB TO 60″NB
Class: 150 LBS, 300 LBS, 600 LBS, 900 LBS, 1500 LBS, 2500 LBS, ASA 150#, ASA 300# DIN ND 6,10,16,25,40 Etc.
Grade : Nickel Alloy 201 (UNS No. N02201)
Our Nickel Alloy 201 Flanges conforms to NACE MR0175/ISO 15156
ASTM B564 Nickel Alloy 201 Flanges Equivalent Grades
STANDARD |
WERKSTOFF NR. |
UNS |
GOST |
AFNOR |
JIS |
BS |
EN |
Nickel 201 |
2.4068 |
N02201 |
НП-2 |
- |
NW 2201 |
NA 12 |
NLC-Ni 99 |
201 Nickel Alloy Flanges Chemical Composition
Grade |
Ni |
Fe |
C |
Mn |
Si |
Cu |
Mg |
Ti |
S |
Nickel 201 |
99.0 min |
0.4 max |
0.02 max |
0.35 max |
0.2 max |
0.25 max |
0.15 max |
0.1 max |
0.01 max |
201 Nickel Alloy Pipe Flanges Mechanical Properties
Density |
Melting Point |
Tensile Strength |
Yield Strength (0.2%Offset) |
Elongation |
8.9 g/cm3 |
1446 °C (2635 °F) |
Psi – 67000 , MPa – 462 |
Psi – 21500 , MPa – 148 |
45 % |
Types Of Available Products AISI, ASTM, DIN, JIS, GB, EN Nickel Alloy 201 Flanges
Nickel Alloy 201 Flanges
201 Nickel Alloy Blind Flanges
ASTM B564 Nickel 201 Slip On Flanges
Nickel UNS N02201 Pipe Flanges
ASTM B564 Nickel 201 BLRF Flanges Manufacturer
B564 201 Nickel Alloy Weld Neck Flanges Manufacturer
ASME SB 564 Nickel 201 RTJ Flanges Stockiest
JIS NW 2201 Threaded Flanges Distributors
Nickel Alloy 201 SWRF Flanges
Top Quality Nickel 201 Socket weld Flanges
201 Nickel Alloy Orifice Flanges Exporter
ASTM B564 Nickel 201 DIN Flanges
AISI Nickel Alloy 201 Forged Flanges/p>
201 Nickel Ring Type Joint Flanges Stockiest in India
Nickel Alloy 201 Reducing Flanges
ASTM B564 Nickel 201 Lap Joint Flanges
Nickel WERKSTOFF NR. 2.4068 Long Weld Neck Flanges
201 Nickel Alloy Screwed Flanges Dealers
ASTM B564 Nickel Alloy 201 SORF Flanges
Nickel 201 Plate Flanges Stockholder
201 Nickel Alloy WNRF Flanges Suppliers
B564 Nickel 201 Spectacle Blinds Flanges Suppliers
ASME SB 564 Nickel Alloy 201 Flanges
AISI Nickel 201 ASTM B564 Flanges
ASTM B564 Nickel 201 Alloy Loose Flanges
Ni Alloy 201 Flange JIS Standard Flanges
