Inconel 600 Pipes & Tubes

Sankalp Alloys Overseas is one of the reputed concerns engaged in the manufacture, supply, wholesale, and export of Inconel 600 Pipes & Tubes. Known for their excellent tensile strength and resistance to corrosion, as well as high heat, these devices are fabricated from nickel, chromium, and iron alloy. The qualities of Nickel Alloy 600 Pipes make them unique elements in engineering functions featuring challenging applications, mainly at high temperatures and in media known to be corrosive.

Inconel 600 Pipes & Tubes Manufacturers, Inconel 600 Pipes & Tubes Suppliers, Inconel 600 Pipes & Tubes Stockists, Inconel 600 Pipes & Tubes Exporters

Inconel 600 Pipes & Tubes Manufacturers in India, Inconel 600 Pipes & Tubes Suppliers in India, Inconel 600 Pipes & Tubes Stockists in India, Inconel 600 Pipes & Tubes Exporters in India

Inconel 600 Tubes are high in strength and offer resistance to corrosion and critical properties in a wide range of engineering projects. These tubes have performed very well in petrochemical plants by operating in high-temperature environments independent of either strength or reactivity. Apart from that, oil refineries and nuclear power plants also operate with equally effective tubes with strong and long-lasting piping solutions. The DIN 2.4816 Inconel Pipe finds use in aerospace due to its tolerance to harsh conditions. The tubes are also used in the automobile industry, mainly dealing with exhaust systems and turbochargers, where excellent qualities are attributed to them.

The principal advantage of using Inconel 600 Pipes is that they are solid, even under significantly soaring temperatures and under contact with corrosive substances like acids or alkaline solutions. This makes them even more challenging, and in such conditions, ordinary metals would lose the fight due to corrosion or thermal stress cracking. Consequently, wear resistance is the characteristic of very high quality inherent in these Inconel UNS N06600 Pipes due to a high content of alloys, making them durable compared to other metals, like stainless steel or copper alloys. They can be easily set in shapes during manufacturing without losing their mechanical properties, which makes them versatile for fabricating anything in a custom-fabricated project.

Inconel 600 Pipes & Tubes contain a nickel-chromium-iron composition with excellent resistance to corrosion, high-temperature sustainability, and high strength. Hence, it can undergo heat treatment related to exothermic applications around 2000°F. With high mechanical strength, Inconel 600 materials are excellent not only in workability but also in good weldability to become one of the favorite materials for many industrial applications.

Inconel 600 Pipes & Tubes Manufacturers in Mumbai, Inconel 600 Pipes & Tubes Suppliers in Mumbai, Inconel 600 Pipes & Tubes Stockists in Mumbai, Inconel 600 Pipes & Tubes Exporters in Mumbai

Specifications of Inconel 600 Pipes & Tubes

Specifications : ASTM B 167 ASME SB 167 / ASTM B 829 ASME SB 829 / ASTM B 517 ASME SB 517
Dimensions : ASTM, ASME and API
Seamless 600 Pipes : 4 to 219mm W. T.: 0.5 to 20mm
Welded 600 Pipes : 5.0 mm – 1219.2 mm
EFW 600 Pipes : 5.0 mm – 1219.2 mm
Size : 15″NB TO 150″NB IN
Specialized in : Large Diameter Size
Schedule : SCH5, SCH10, SCH40, STD, SCH80, SCH160
Type : Seamless / ERW / Welded / Fabricated / LSAW Pipes
Form : Round, Hydraulic Etc
Length : Single Random, Double Random & Cut Length.
End : Plain End, Beveled End, Treaded



Grade UNS No Old British Euronorm GOST Japanese JIS
BS En No AFNOR
Inconel 600 N06600 NA 13 NiCr15Fe 2.4816 NC15FE11M МНЖМц 28-2,5-1,5 NCF 600

Chemical Alloyion Of Inconel 600 Pipes & Tubes

Grade C Mn Si Fe S Cr Cu Ni
600 min. 6.0 14.0 72.0
max. 0.15 1.0 0.5 10.0 0.015 17.0 0.5

Mechanical Properties Of Inconel 600 Pipes & Tubes

Grade Tensile Strength (MPa) min Yield Strength 0.2% Proof (MPa) min Elongation (% in 50mm) min Hardness
Rockwell B (HR B) max Brinell (HB) max
600 Psi – 95,000 , MPa -655 Psi – 45,000 , MPa – 310 40
